Disc Type Horizontal Beads Mill

The Disc Type Horizontal Beads Mill is a closed continuous production machine for grinding liquid materials. It is one of the most popular wet grinding machines in the market with good performance and mature structure. And it is characterized in simple operation, good reliability and full specifications. Its sealing structure adopts double end mechanical seal with self-lubricating system, sealing liquid is optional, more reliable and durable. The machine is also with temperature, pressure monitor and protection to ensure the quality of the finished product. Using cerium stabilized zirconium bead (80% Zirconia content), suitable for grinding paste with fineness requirements of 10-20 micron. It is widely used in coating, paint, ink, pesticide and other industries.

2023080909292491
Disc Type Horizontal Beads Mill
  • Materials Viscosity
    ≤20,000 cps
  • Production Capacity
    10-4000L/h
  • Application Industry
    Coating, paint, ink, pesticide and other industries
  • Applicable Materials
    Paste with viscosity below 20,000 cps and grinding fineness can be down to 10micron, such as primer, intermediate coating, pesticide suspension agent etc.

Product Advantages

  • Low energy consumption ratio and high cost performance
    Driven by a motor to transmit power to the main shaft through big and small pulleys, which is easy to start; The grinding disc is with a special disc structure, which brings high efficiency and low power consumption; It is a product with high cost performance among the different beads mills.
    01
  • Safe monitoring, stable finished products
    With site control panel, which is integrated with the machine frame, easy.The grinding chamber is equipped with a special cooling water jacket. When the machine running, input cooling water for cooling. The cooling result is excellent. The conventional temperature rise is less than 10ºC. The equipment is equipped with temperature and pressure monitoring, which can set the "protection value" to ensure finished product quality.
    02
  • Safe monitoring, stable finished products
    The outer cooling jacket adopts a honeycomb design with excellent cooling effect to ensure that the grinding heat is exchanged in time. The water temperature, material temperature, material pressure, water pressure, air pressure and other real-time monitoring and protection system ensure proper operation of the machine.
    03
  • Full specification, can be customized
    Full specification from 20L to 300L. Can be customized to be Explosion proof type.
    04

Working Principle

The delivery pump circulates materials from materials container (tank) to the grinding chamber. The main shaft of the grinding chamber is equipped with a number of disc-type grinding discs, which drive the grinding medium in the chamber to collide with each other. The granules in the materials are continuously rolled by the grinding medium. At the same time, the separating screen keeps the grinding medium in the grinding chamber, and the material continuously returns to the material container (tank) from the grinding chamber in a circular way, so as to obtain finished products with smaller particle size and narrower particle size range.

Disc Type Horizontal Beads Mill

Recommended Product

Technical Parameter



Specification



Chamber volume

(L)



Power

(KW)



Main shaft speed

(rpm)



Grinding medium

(mm)



Capacity

(L/h)



Cooling water consumption

(L/h)

SWS-20 20 18.5 1030 1.6~2.2 120-500 800-1500
SWS-30 30 22 1030 1.6~2.2 150-600 800-1500
SWS-50 50 30 830 1.6~2.2 300-1000 1500-2500
SWS-100 100 55 568 1.6~2.2 500-2000 2000-4000
SWS-300 300 110 468 1.6~2.2 1000-4000 2000-6000
