Straight Discharge Screen
Straight discharge screen is based on single/double horizontal vibration motor as vibration source. Vibration motor is on one side of the body. The materials will be under the action of the vibration source after they go into the machine and do elliptical orbit movement. After materials going to the sieve, the vibration force will repeatedly and continuously peel, break up and reorganize the materials to have them go through the sieve rapidly. The materials cannot go through the sieve will following the Trajectory of the machine and go to the discharging port to finish the sieving work.
-
Sieving Fineness＜600 mesh
-
Screening Area0.21—1.52㎡
-
Application IndustrySuitable for sieving materials in industries such as Food, paper making, metallurgy, pharmaceutical, environmental protection, chemical, dyestuff etc.. (For more application industry, please click “Free Consultation”)
-
Applicable MaterialsApplicable for particle-size segregation situation, such as food additives, pharmaceutical intermediates, pigments, ceramic material, alumina, silica sand, coating material, metal powder, Chinese herbal medicine etc.
Product Advantages
-
1. Small volume, light, remove easily, discharging port direction can be adjust as required, coarse and fine material will be discharged automatically, automatic or manual operation. Can do continuous production for 24 hours.01
2. Sieving with low consumption,high precision, high efficiency, and is applicable to any powder, granule or mucus.
3. Closed tightly, liquid does not leak, powder does not fly in the sky; No screen blocking, screening fineness is up to 500 mesh.
4. The unique grid structure(Composite type), the screen can be used for a long time, convenient to replace the mesh and only need 3 to 5 minutes, simple operation, easy cleaning and can meet the GMP standard.
5. No mechanical action, simple and easy to maintain, single layer or multi-layer are optional, and the part contacting with materials is stainless steel (except for medical use).
6. Ultra-low mute design, it is about 70 decibels during normal working.
Working Principle
Having a vertical motor as the vibration source, and the motor is with bias hammer mounted on both the top and bottom of the motor to make the rotation motor to move in there directions: horizontal, vertical and inclined direction. And the materials on the sieve will be under the actions through the rotation of the motor and do spreading movement to realize sieving purpose. The vibration source can be single motor and double motors. Different ways to adjust the materials trajectory which increases its applicability obviously. That the materials discharged directly also increased the processing capacity.
Recommended products
Technical Parameter
| Model | Mesh diameter (mm) | Effective mesh area (㎡) | Specification of mesh size (mesh/mm) | Mesh layers | Vibration times | Power
(Kw) |
Dimension (mm) |
|---|---|---|---|---|---|---|---|
| SSZP-600 | Φ520 | 0.21 | ＜600
mesh |
1 | 1500 | 0.12 | 740*600*560 |
| SSZP-800 | Φ720 | 0.40 | 1500 | 0.18 | 1010*800*600 | ||
| SSZP-1000 | Φ890 | 0.62 | 1500 | 0.18 | 1200*970*640 | ||
| SSZP-1200 | Φ1090 | 0.93 | 1500 | 0.25 | 1430*1170*700 | ||
| SSZP-1500 | Φ1390 | 1.52 | 1500 | 0.55 | 1780*1470*760 |
Industry application
