Roof Dust Collector
Roof Dust Collector is a kind of de-dusting equipment used in bins. It can be divided into bag-type and cartridge type. Roof dust collector is nowadays widely used in powder pneumatic conveying process and the filtration area are designed according to capacity, proportion of gas and powder, air pressure, air speed and etc. parameters.
-
Dust ConcentrationInlet＜200g/m³，Outlet＜50mg/m³
-
Filtration Area24~84㎡
-
Application IndustrySuitable for dust collect of food, paper making, metallurgy, pharmacy, environment protection, chemical industry, dye and etc industries. (more information please click FREE CONSULTATION)
-
Applicable MaterialsAll positions where there is raise dust, especially for power ex-proof factories and industries has high requirements to tail gas treatment, such as pigment, ceramic materials, aluminium oxide, quartz sand, food additive, metal powder, Chinese herbal medicine and etc.
Product Advantages
-
1. High efficiency, normally above 99% and the dust concentration is below tens of mg/m³, high resolution ratio to submicron fines.01
2. Simple structure,, easy to operate, easy to change bags and long service life.
3. Connect hopper with flange and its global design makes it easy to transport and install.
Working Principle
Roof dust collector is a removable metal filtration cylinder and consists of support frame, top cylinder, control cabinet, filtration bag/cartridge, sealed cylinder, protection grid, connection clamp, welding flange, sealing gasket and etc. Dust, carried by gases, are held up on filtration layer. Therefore, solid are separated from gases and the solid are stored in the collector at the bottom.
Recommended products
Technical Parameter
Dust concentration: inlet＜200g/m³，outlet＜50mg/m³
Filtration area:24~84㎡
Industry application
